We have an excellent used condition, Feeler FTC20 CNC lathe for sale.

Specification are as follows for this cnc machine:

Fanuc OT Control
Swing over the bed 600mm
Max Turning Dia 350mm
Max Turning Length 343mm
X Axis Travel 175mm
Z Axis Travle 380mm
Rapid Traverse X and Z Axis 24m/min
Spindle nose A2-6
Max Spindle Speed 4,500rpm
Spindle Bore through Draw Tube 50mm
25mm Square Shank Tooling
8 Station Turret
15HP Main spindle motor (continuous)
Coolant Tank Capacity 100 Litres
Year of manufacture 1999
Dimensions for Transport 3.1m x 1.7m x 1.8m (L x W x H)
Weight 3.5 Tonne
Comes with the following accessories:

3 Jaw chuck Hydraulic Chuck
Parts Catcher
Manual Position Tailstock with M Code Quill activation
Tool Setter
This CNC Lathe is in our warehouse ready for inspection under power. e.

We are always interested in purchasing metalworking machinery & surplus equipment, if you are closing down or have a quantity of machines you need gone in a hurry, please feel free contact us here at Newmac Equipment

1999 FEELER FTC-20

We have a Hartford VMC 850S vertical machining centre for sale

Specifications for this VMC are as follows

Table size 1000mm x 450mm
XYZ Travels X-850mm, Y-510mm, Z-510mm
Max spindle speed 8000 rpm
Spindle taper BT40
Feature 20 position tool carousel
Mitsubishi Meldas 500 CNC control
Power requirements 415 volt
Overall dimensions 2.4m x 2.3m x 2.4m high
Weight 5.6 tons
Year of manufacture 1999

We have run this Hartford 850S VMC & all works well.

We recommend customers pay us a visit to inspect machinery, where we are happy to test run machinery in our warehouse, that way it gives you peace of mind that the machine will do your job prior to purchase.

This centre lathe is in our warehouse so please feel free to call us for more information & price or pop in to inspect the machine at your convenience.

We are always interested in purchasing metalworking machinery & surplus equipment. Should you be looking at Downsizing, Relocating, Closing Down or have machinery that is surplus to requirements, we would appreciate the opportunity to assist in any way we can.

HARTFORD VMC 850S

We have an excellent used condition, Atlantic Multi ATI 70 Punch & Shear for sale.

For two operator utilisation, the hydraulic system is activated by two shielded foot controls, one operating the punch end cylinder, the other operating the shear end cylinder.
The shear cylinder provides the power to the 3 shearing stations and the notch stations.

The system gives accurate power inching at all five work stations and allows the machine to stopped at any position giving safe and accurate tool setting and work positioning.
Z Limit switches at both ends of the machine control stroke length at all stations.

Centralised lubrication is metered by one-shot system, is only one feature of the low maintenance requirement.

 Large punch table with multi-purpose bolster
 Removable table block for overhang channel.
 Punch table, shear table a notch table standard equipment
 Power inching and adjustable strokes at punch & shear end
 Centralised pressure lubrication
 Wide variety of applications for large hole punching: bar bending, tube notching,
 Mitre cut flanges of angle under the shear blade
 Work station guards standard fitment
 Two cylinder operation
 Overload relief on the hydraulic system
 Interchangeable bearings, seals and valves readily available in Australia.
 Punch adaptors
 Swing away punch stripper unit
 Easy change punch holder
 One low volt halogen lamp on a movable magnetic base
 Fine adjustment facility to the punch stroke
 Measuring scales in the notch table
 1.0m long touch and cut ruled length stop
 Universal die bolster
 Heavy-duty support tables with guides at the shear station and notch station
 Heavy-duty punch table with guides and backstop
 Shear body blade with 4 cutting edges
 Section arm & body blade with 1 cutting edge
 Angle cutting arm & body blades with 4 cutting edges
 Rectangular notch bolster blades with 4 cuttings edges
 Work station guards

Machine specifications:
TECHNICAL SPECIFICATIONS: Based on material strength of 450 N/mm².

Model: MULTI 70
Maximum pressure: 70 Ton

Punching Station
Maximum Capacity: 26 x 20mm
Diameter x Thickness: 57 x 9mm
Stroke Length: 55mm
Standard Throat Depth: 305mm

Shearing Station
Flat Bar  Max Thickness: 300 x 20mm
Flat Bar  Max Width: 375 x 15mm
Angle Flange Trim  Max 45º: 100 x 15
Working Height: 890mm

Angle Cutting
90º Cut: 130 x 13mm
45º Mitre (true int/ext): 70 x 10mm

Section Cutting
Round/Square: 45mm

Notching
Material Thickness: 10mm
Width  Rectangle: 45mm
Depth  Rectangle: 90mm

Technical Data
Motor Power: 5,5Kw
Weight: 1620Kgs
Machine dimensions: 164 x 71 x 183

We have run this machine. All functions are working. This ironworker is in our warehouse so please feel free to call us for more information or pop in to inspect the machine at your convenience.

We are always interested in purchasing metalworking machinery, if you have machines surplus to requirements or you are closing down, please feel free to contact us here at Newmac Equipment.

ATLANTIC MULTI ATI 70

We have a near new condition, single phase, First CL1-1/2VS turret milling machine for sale.

Specifications are as follows
Table size 1270mm x 230mm
Spindle speeds 50 to 3750 rpm
Spindle taper NT30
Main motor 2HP
Machine voltage 240 volt

Comes with/Features
X & Y power feeds
Fagor 3 axis digital read out
Coolant system
Work lights

We have run this milling machine & all works well.

We recommend customers pay us a visit to inspect machinery, where we are happy to test run machinery in our warehouse, that way it gives you peace of mind that the machine will do your job prior to purchase.

This centre lathe is in our warehouse so please feel free to call us for more information & price or pop in to inspect the machine at your convenience.

We are always interested in purchasing metalworking machinery & surplus equipment. Should you be looking at Downsizing, Relocating, Closing Down or have machinery that is surplus to requirements, we would appreciate the opportunity to assist in any way we can.

FIRST CL1 1/2VS TURRET MILLING MACHINE

We have an LNS Eco Load Short Magazine Barfeed for sale. The barfeed is in as new condition, having only been used once or twice.

General Specifications

Overall Capacity 2-5/8 x 60
Siemens TD200 DRO Push Button Control
Pendant Control
The barfeed unit retracts on linear rails to facilitate changes in spindle liner
Overall dimensions 1.8m x 1.1m x 1.5m high
Weight  appox 450kgs

This LNS Eco Load Short Magazine Barfeed is in our warehouse so please feel free to call us for more information or pop in to inspect the machine at your convenience.

We are always interested in purchasing metalworking machinery & surplus equipment, if you have one machine or a quantity of machines you want to sell, please feel free to give us a ring.

LNS CNC ECO LOAD BARFEEDER

We have an excellent used condition SM MD40XPF geared head pedestal mill drill for sale.

Specifcation are as follows

Max drilling capacity 40mm
Max milling capacity of milling head 80mm
Spindle travel 120mm
Spindle taper MT4
Head swivels plus or minus 45°
Spindle speeds, 75 to 1600 rpm
Throat depth 272mm
Table size 600mm x 190mm
XYZ travels 610mm x 370mm x 190mm
Power required 240 volt
1.1kw main motor
Overall dimensions 870mm x 720mm x 1830mm high
Weight 320kgs

Features

Power quill feed 0.04 to 0.12 mm/rev
Wind up/down table & head

For customers who wish to pay us a visit, we are happy to test run machinery in our warehouse, that way it gives you peace of mind that the machine will do your job prior to purchase.

This geared head drill is in our warehouse so please feel free to call us for more information & price or pop in to inspect the machine at your convenience.

We are always interested in purchasing metalworking machinery & surplus equipment. Should you be looking at Downsizing, Relocating, Closing Down or have machinery that is surplus to requirements, we would appreciate the opportunity to assist in any way we can.

STEELMASTER SM MD40XPF GEARED HEAD PEDESTAL MILL DRILL

Archdale MT5 x 1600mm radial arm drilling machine.

ARCHDALE MT5 X 1600MM

We have a CIG Transmig 275 Mig Welder  for sale

For customers who wish to pay us a visit, we are happy to test run machinery in our warehouse, that way it gives you peace of mind that the machine will do your job prior to purchase.

This Mig Welderis in our warehouse so please feel free to call us for more information & price or pop in to inspect the machine at your convenience.

We are always interested in purchasing metalworking machinery & surplus equipment, if you have one machine or a quantity of machines you need gone, please feel free contact us here at Newmac Equipment

CIG TRANSMIG 275 MIG WELDER

We have an Erlo TCA 50/60 Geared head drill for sale

Specifications are as follows

Table size 560mm x 560mm / Working area 420mm x 420mm
Max drill size 60mm
Spindle taper Morse taper 5
Distance from base plate to spindle nose 1250mm quill fully up
Distance from centre of the spindle to the column 400mm
Spindle speeds, 9 speeds 45 to 1115 rpm
Quill travel 260mm
Motor Hp/Kw 5.5HP 4KW
Power requirements 3 Phase 415 volt
Weight approx. 1 ton

Features

Forward & reverse
Power feeds
Comes with

Coolant system

For customers who wish to pay us a visit, we are happy to test run machinery in our warehouse, that way it gives you peace of mind that the machine will do your job prior to purchase.

This geared head drill is in our warehouse so please feel free to call for more information & price or pop in to inspect the machine at your convenience.

We are always interested in purchasing metalworking machinery & surplus equipment. Should you be looking at Downsizing, Relocating, Closing Down or have machinery that is surplus to requirements, we would appreciate the opportunity to assist in any way we can

ERLO TCA 50/60 GEARED HEAD DRILLING MACHINE

We have a used Transmig 200 Mig welder for sale.

Requires 415 volt power

Max 200 amp

CIG TRANSMIG 200

We have a Used, WMW Mikromat SFW 200×600 surface grinder for sale.

Specifications are as follows

Table size 750mm x 200mm
Magnetic chuck size 600mm x 205mm
Max grinding wheel dia. 200mm
power requirements, 3 phase 415 volt
Overall dimensions 1.8m x 1.3m x 1.95m high
Weight 1.1 tons

Comes with

Collant system

The surface grinder is in our warehouse so please feel free to contact us or pop in to inspect the machine at your convenience.

We are always interested in purchasing metalworking machinery, if you have machines surplus to requirements or you are closing down, please feel free to contact us here at Newmac Equipment.

WMW MIKROMAT SFW 200×600 AUTOMATIC HYDRAULIC SURFACE GRINDING MACHINE

We have in used condition a Kleen 3.6m 60 Tonne Hydraulic Brake Press for sale

Bending Length 3.6m
60 Tonne
Single Axis
Manual Back Guage
Three phase 415V
Dimensions for Transport 3.7m x 1.0m x 2.3m (L x W x H)
Weight 5 Tonne
Comes Complete With:

Hydraulic System
Top and Bottom Tooling
Rear Safety Guarding

We are always interested in purchasing metalworking machinery & surplus equipment, if you have one machine or a quantity of machines you need to sell, please feel free contact us here at Newmac Equipment

This Brake Press is in our warehouse so please feel free to pop in to inspect the machine at your convenience.

KLEEN UNKNOWN
