Newmac Equipment

We have a Colchester Triumph Electronic  CNC Teach lathe for sale

Stock # 4169

Specifications are as follows

Fanuc 20TControl
Spindle Nose D1-6 Camlock
Spindle speed range 13 to 2500 rpm
Main motor HP/KW 10/7.5
Max Turning Dia 400mm
Max Turning length 1180mm
Hole through spindle 54mm
Supply voltage needed 415 volt
Overall dimensions Machine  2600mm x 1500mm x 1670mm High
Weight Machine approx 3000kgs
Year of Manufacture 1996

Accessories included

Quick Change Toolpost and tool holders
3 Jaw Chuck
Features

Teach in Software
Coolant system
Worklight

We recommend customers visit our warehouse to inspect the machinery in person. Our team is more than happy to offer to test run the equipment to give you the peace of mind that it will perform to your requirements before making a purchase. That way, you can make an informed decision and feel confident in your investment. We pride ourselves on providing exceptional customer service and believe that this personalized approach allows us to exceed your expectations.

We welcome any inquiries about the machine and invite you to contact us at

We would like to extend a note to all prospective customers. We are happy to provide details of freight companies that transport machines anywhere in Australia or worldwide. However, we want to remind customers that the machines are not insured during transport by either the transport companies or Newmac Equipment. We strongly advise that customers speak with their usual insurance company to take out transport insurance.

Considering selling your machinery?

We are always interested in purchasing metalworking machinery & surplus equipment, if you have one machine or a number of machines you need gone, please feel free contact us here at Newmac Equipment.

1996 COLCHESTER ELECTRONIC

We have a Harrison Alpha 330 Plus  CNC Teach lathe for sale

Harrison lathes are manufactured in the UK and have been widely used in training facilities and general engineering workshops for many years. They are known for their straightforward operation and practical design.


The Alpha series combines manual operation with CNC capability. This machine is fitted with the Harrison Alpha conversational (teach-in) system along with a Fanuc 21TB control. The conversational system allows operators to create programs using a step-by-step input method, without requiring full G-code programming.

Specifications are as follows

Fanuc 21 TBControl
Spindle Nose D1-4 Camlock
Spindle speed range 0 to 3500 rpm
Main motor HP/KW 7.5/10
Max Turning Dia 330mm
Max Turning length 1000mm
Hole through spindle 42mm
Supply voltage needed 415 volt
Overall dimensions Machine  2040mm x 1200mm x 1550mm High
Weight Machine approx 1200kgs
Year of Manufacture 1999

Accessories included

Quick Change Toolpost and tool holders
3 Jaw and 4 Jaw Chuck
Travelling Steady Rest

Features
Teach in Software
Coolant system
Worklight

We recommend customers visit our warehouse to inspect the machinery in person. Our team is more than happy to offer to test run the equipment to give you the peace of mind that it will perform to your requirements before making a purchase. That way, you can make an informed decision and feel confident in your investment. We pride ourselves on providing exceptional customer service and believe that this personalized approach allows us to exceed your expectations.

We would like to extend a note to all prospective customers. We are happy to provide details of freight companies that transport machines anywhere in Australia or worldwide. However, we want to remind customers that the machines are not insured during transport by either the transport companies or Newmac Equipment. We strongly advise that customers speak with their usual insurance company to take out transport insurance.

Considering selling your machinery?

We are always interested in purchasing metalworking machinery & surplus equipment, if you have one machine or a number of machines you need gone, please feel free contact us here at Newmac Equipment.

HARRISON ALPHA ALPHA 330 PLUS

We have an excellent used condition, Kingsland 55XS Punch & Shear Ironworker for sale.

Stock# 4668

Hydraulic Two Man Operation 55 Tonne Capacity
Punch Diameter Capacity in mild steel 32 x 13mm/38 x 10mm
Angle Iron Capacity in mild steel at 90° 130 x 13mm
Angle Iron Capacity in mild steel at 45° 70 x 10mm
Round Bar Capacity in mild steel 45mm
Square Bar Capacity in mild steel 45mm
Shearing Capacity in mild steel plate 230mm x 20mm thick or 375mm x 10mm thick
Notching Capacity in mild steel 45mm x 90mm deep x 10mm thick
See photos of charts on machine

We have run this machine. All functions are working. This Ironworker is in our warehouse so please feel free to pop in to inspect the machine at your convenience.

We are always interested in purchasing metalworking machinery, if you have machines surplus to requirements or you are closing down, please feel free to contact us here at Newmac Equipment.

We would like to extend a note to all prospective customers. We are happy to provide details of freight companies that transport machines anywhere in Australia or worldwide. However, we want to remind customers that the machines are not insured during transport by either the transport companies or Newmac Equipment. We strongly advise that customers speak with their usual insurance company to take out transport insurance.

KINGSLAND 55XS

We have an ex-education department Dashin Champion 2500VS Centre Lathe for sale.

This is a Taiwanese-built variable speed centre lathe, manufactured by Jesco. This example is fitted with a Carmar SW4000 two-axis digital readout, quick change toolpost, and the standard variable speed control system with constant surface speed (CSS) function, allowing the spindle to hold a consistent cutting speed as diameter changes during facing or taper work.

This used unit has come into Newmac in good working order and includes both the standard 3-jaw and 4-jaw chucks, fixed & travelling steadies

Specifications
Swing over bed: 390mm
Swing in gap: 610mm
Swing over cross-slide: 240mm
Distance between centres: 1250mm
Spindle bore: 55mm
Centre height: 190mm
Bed width: 270mm
Spindle nose: D1-6
Headstock spindle taper: MT6
Tailstock taper: MT4
Cross slide travel: 230mm
Compound slide travel: 120mm
Leadscrew type: metric
Metric cross feed: 0.02  0.5mm/rev
Metric longitudinal feed: 0.040  1.00mm/rev
Metric thread pitch range: 39 steps, 0.2  14mm
Imperial thread range: 45 steps, 2  72 TPI
Spindle speed: variable, 18  2500rpm (high/low range selector)
Motor power: 5.5kW / 7.5hp
Voltage: 415V
Nett weight: 1500kg (approx.)

Included with this machine
3-jaw and 4-jaw chucks
Quick change toolpost
Fixed & travelling steadies
Digital readout (Carmar SW4000)
Coolant system
Work light

Freight options
We are happy to provide freight quotes with a full delivery address

We recommend customers pay us a visit to inspect machinery, where we are happy to test run machinery in our warehouse, that way it gives you peace of mind that the machine will do your job before purchase.

This lathe machine is in our warehouse so please feel free to call us on  for more information & price or pop in to inspect the machine at your convenience.

We are always interested in purchasing metalworking machinery & surplus equipment. Should you be looking at Downsizing, Relocating, Closing Down or having machinery surplus to requirements, we would appreciate the opportunity to assist in any way we can.

We would like to extend a note to all prospective customers. We are happy to provide details of freight companies that transport machines anywhere in Australia or worldwide. However, we want to remind customers that the machines are not insured during transport by either the transport companies or Newmac Equipment. We strongly advise that customers speak with their usual insurance company to take out transport insurance.

3 Phase Power  Please Note
This machine does not include a plug. When 3 phase machinery is decommissioned from industrial use, it is typically disconnected  from a switchboard by an electrician  meaning no plug is fitted, and in some cases the cable may also be absent.

As a machinery dealer, we are not electricians and are unable to supply or fit plugs. Buyers will need to arrange connection through a licensed electrician. This is no different to purchasing new 3-phase machinery, which also requires a licensed electrician for installation.

On occasion, a machine will arrive with a plug already fitted  in that case, it stays. For the same reason we dont fit plugs, we dont remove them either.

DASHIN CHAMPION 2500VS CENTRE LATHE

We have for sale a Holroyd 40" Gear Hobbing Machine manufactured by Holroyd in the UK
The machine comes complete with a large range of change gears

Stock No 4222

Max workpiece diameter 40? / 1,016mm
Max Spur Gear width 12"/300mm
Max Pitch in Wormwheel with Hob 1 3/4'' Circular Pitch
Max Size of Hob 8'' Dia x 9 1/4'' Long
Power requirement for Drive Motor 7.5hp/415V
Power Requirement of Elevation Motor 2.5hp/415V
Machine transport Dimensions 3.4m  x 1.4m x 2.7m High
Machine Weight 6 Tonne approx

We recommend customers visit our warehouse to inspect the machinery in person. Our team is more than happy to offer to test run the equipment to give you the peace of mind that it will perform to your requirements before making a purchase. That way, you can make an informed decision and feel confident in your investment.

Considering selling your machinery? We buy as well as sell machinery. Downsizing, relocating, closing down, or having surplus equipment. We are always on the lookout for quality machinery to buy. Please do not hesitate to contact us to discuss your machinery needs and how we can help you.

We would like to extend a note to all prospective customers. We are happy to provide details of freight companies that transport machines anywhere in Australia or worldwide. However, we want to remind customers that the machines are not insured during transport by either the transport companies or Newmac Equipment. We strongly advise customers to take out transport insurance with their usual insurance company.

HOLROYD 40''

SEW-Eurodrive MOVITRAC LTE-B+ Variable Speed Drive for sale.

New condition. Was purchased for a project but never used. A genuine opportunity to pick up a top-brand European drive without paying full new-unit price.

What it does: A variable speed drive controls how fast an electric motor runs. Instead of a motor only having one speed (full on), this unit lets you dial the speed up or down, start and stop smoothly, and even run in reverse. Commonly used on pumps, conveyors, fans, compressors, and machine tool spindles  anywhere you need adjustable speed rather than fixed on/off.

Specifications:

Model: MOVITRAC LTE-B+ (MCLTEB0040-5A3-4-40)
SEW Part No: 18262562
Input: 380480V, 3-phase, 50/60Hz, 11.5A
Output: 0500V, 3-phase, 0500Hz, 9.5A
Rated: 4kW (5HP)
Enclosure: IP66 / NEMA 4X  sealed, washdown-rated for dusty or wet conditions
Certifications: UL Listed, CE, EAC
Made in UK

The sealed IP66 enclosure means this one is built for tougher environments  workshop floors, food processing, or anywhere a standard drive wouldn't cope.

Condition: as new, still in original packaging.

SEW EURODRIVE MOVITRAC LTE-B+ VARIABLE SPEED DRIVE

We have a Woodfast Planer/Jointer for sale.
Cutter width 150mm
Table size 1200 x 170mm
415V Three Phase
Dimensions for Transport 1200 x 500 x 960mm High
Weight 100kg

We have test run this machine in our warehouse & all is in  working condition. For customers who wish to pay us a visit, we are happy to test run machinery, that way it gives you peace of mind that the machine will do your job prior to purchase

WOODFAST PLANER JOINTER

We have a Suhang Machinery, motorized sheet metal  Coil Car for sale.


Stock # 4251

Specifications are as follows

Max coil width 600mm
Hydraulic Coil Lift
Power requirements 3 phase, 415 volt
Max overall dimensions 2,050mm x 900mmm x 7500mm high
Weight 1,000kgs

For customers who wish to inspect this machine, we are happy to test-run machinery in our warehouse, that way it gives you peace of mind that the machine will do your job before purchase.

The machine is in our warehouse so feel free to inspect the machine at your convenience.

Thinking of selling your used or surplus equipment? Looking at Downsizing, Relocating, Closing Down or have machinery that is surplus to requirements. We are always looking for machinery to buy,  so would appreciate the opportunity to assist in any way we can.

We would like to extend a note to all prospective customers. We are happy to provide details of freight companies that transport machines anywhere in Australia or worldwide. However, we want to remind customers that the machines are not insured during transport by either the transport companies or Newmac Equipment. We strongly advise that customers speak with their usual insurance company to take out transport insurance.

The slide show below can be paused by hovering the mouse cursor over the current photo. It will resume when the cursor is moved off the photo

SUHANG MACHINERY COIL CAR

Genuine BIG Daishowa BT40  coolant-through tool holder for sale.

Side lock type. Delivers oil coolant  through the tool for improved chip clearance and tool life on deep drilling and hole-making work. In good used condition and ready to fit straight onto your machine. Ideal for adapting standard machining centres to through-coolant tooling. Genuine BIG Daishowa quality  built for precision and long service life.

Model: BT40-OSL32N-165 (stamped on flange)
Taper: BT40
Type: Hi-Jet coolant adaptor, side lock
Max speed: 8,000 rpm
Max coolant pressure: 20 kg/cm² (285 PSI)
Coolant delivery: through-tool system
Condition: used, functional, normal surface wear

DAISHOWA BIG DAISHOWA BT40 COOLANT-THROUGH TOOL HOLDER

In near-new condition, we have an ex-school Hafco BM 62VE Turret Milling Machine for sale.

This BM-62VE turret mill is set up and ready for work, with power feed, digital readout, and an air power drawbar already fitted  no add-ons needed to get started.

The hardened and ground work table and slide-ways, combined with Turcite B coating on the X and Y-axis slide-ways, keep the machine running smooth and precise with minimal friction. The mechanical variable speed head gives a wide 60-450 RPM (low) to 450-3600 RPM (high) range, and the NT40 spindle taper with chrome and ground quill handles a broad range of tooling. Power feed on the X and Y axes and a powered Z-axis take the effort out of repetitive work, while the one-shot lubrication system keeps maintenance simple.

Included with the machine: 3-axis digital readout and an air-powered drawbar which is an extra not fitted to the oringinal machine.

Specifications
Table size: 1370 x 254mm
Axes travel: X 965mm / Y 415mm / Z 385mm
Spindle speed: variable 60-3600 RPM
Spindle taper: NT40
Spindle travel / diameter: 127 / 105mm
Quill power feed: 0.038 / 0.076 / 0.152 mm per rev
Motor: 5HP / 3.75kW, 415V
Hardened & ground work table and slide-ways
Turcite B coated X & Y-axis slide-ways for smooth, low-friction operation
Align power feeds on X, Y & Z-axis quill feed
3-axis DRO fitted
Air power drawbar fitted (extra upgrade on this unit)
Coolant system and worklight fitted
Weight: 1555kg
Manufactured July 2013

3 Phase Power  Please Note
This machine does not include a plug. When 3 phase machinery is decommissioned from industrial use, it is typically disconnected  from a switchboard by an electrician  meaning no plug is fitted, and in some cases the cable may also be absent.

As a machinery dealer, we are not electricians and are unable to supply or fit plugs. Buyers will need to arrange connection through a licensed electrician. This is no different to purchasing new 3-phase machinery, which also requires a licensed electrician for installation.

On occasion, a machine will arrive with a plug already fitted  in that case, it stays. For the same reason we dont fit plugs, we dont remove them either.

Inspection & Testing
We recommend customers visit our warehouse to inspect the machine in person. A test run can be arranged so you can assess operation prior to purchase and make an informed decision.

Selling Machinery?
We buy as well as sell machinery. If you are downsizing, relocating, closing down, or have surplus equipment, please contact us to discuss your machinery.

Freight & Insurance
We are happy to provide details of freight companies that transport machinery Australia-wide or internationally. Please note that machines are not insured during transport by either the transport companies or Newmac Equipment. Customers are strongly advised to arrange their own transport insurance through their insurer.

HAFCO METALMASTER BM 62VE TURRET MILLING MACHINE

We have an ex-TAFE Takang TK 330 Centre Lathe for sale in good used condition. Stock # 4101

Takang is a well-regarded Taiwanese manufacturer and are known for their solid construction, reliability, and long service life in both training and industrial environments.

This is not a Chinese lathe. It is a heavy, high-quality, industrial-grade Taiwanese machine designed for continuous use.

Stock # 4101

Specifications are as follows

Swing Over Bed 330mm
Swing Over Saddle 1600mm
Distance Btw Ctrs 800mm
Spindle Bore 42mm
Spindle mount D1-5 Camlock
Spindle Speeds 8 Speed 75 to 2000 rpm
Power requirements 3 phase, 415 volt
Spindle Motor 3hp
Overall dimensions 2.2m x 1.0m x 1.4m high
Approx. weight 2 tonnes
Accessories

3 & 4 Jaw chuck/Face Plate/Drive Dog Plate
Fixed Steady Rest (Without Clamp Plate)
Coolant System, can be heard running

We recommend customers pay us a visit to inspect machinery, where we are happy to test run machinery in our warehouse, that way it gives you peace of mind that the machine will do your job before purchase.

This Lathe is in our warehouse so please feel free to pop in to inspect the machine at your convenience.

We are always interested in purchasing metalworking machinery & surplus equipment. Should you be looking at Downsizing, Relocating, Closing Down or having machinery surplus to requirements, we would appreciate the opportunity to assist in any way we can.

We would like to extend a note to all prospective customers. We are happy to provide details of freight companies that transport machines anywhere in Australia or worldwide. However, we want to remind customers that the machines are not insured during transport by either the transport companies or Newmac Equipment. We strongly advise that customers speak with their usual insurance company to take out transport insurance.

TAKANG TK 330

We have a Spiral Milling Attachment for sale

Key Features of this Unit
Function: It connects directly to the table/work area of a  mill to facilitate the cutting of helical gears, reamers, and spirals by linking the rotation of the indexing head to the tables lead screw feed using a train of change gears.

Distinct Shape: The uniquely contoured mounting base plate (with the multi-slot segment profile visible on the table) and the specialized green-painted tailstock housing are signature traits of Deckel Milling Machine accessories, however there are no markings to determine the machine manufacturer

We recommend customers visit our warehouse to inspect the machinery in person. Our team is more than happy to offer to test run the equipment to give you the peace of mind that it will perform to your requirements before making a purchase. That way, you can make an informed decision and feel confident in your investment.

Are you considering selling your machinery?
We buy as well as sell machinery. Downsizing, relocating, closing down, or having surplus equipment. We are always on the lookout for quality machinery to buy. Please do not hesitate to contact us to discuss your machinery needs and how we can help you.

We would like to extend a note to all prospective customers. We are happy to provide details of freight companies that transport machines anywhere in Australia or worldwide. However, we want to remind customers that the machines are not insured during transport by either the transport companies or Newmac Equipment. We strongly advise that customers speak with their usual insurance company to take out transport insurance.

UNKNOWN SPIRAL
